Incinerator (TS10 PLC)

Basic Info.

Model NO.:TS10 PLC
Pullution Sources:Solid Waste Processing
Processing Methods:Physics
Export Markets:Global

Additional Info.

Trademark:Clover
Packing:Wooden Carton
Standard:10 kg per hour
Origin:China
Production Capacity:1500units/Yesr

Product Description

Nanjing Clover Medical Technology Co., Ltd. is a leading waste incinerator Maker in China.

Key Features:  * All versions with Dual combustion chamber.  * Stainless Steel chimney/stack, long life. *according to order  * High fever, long life of incinerator.  * Free or minimal installation on site.  * High burn rate, from 10kgs to 500kgs per hour, up to 6ton per day.  * PLC Control Plane. *according to order  New Design for pet animal cremation enterprise.  * One year guarantee on incinerator and parts in stock.

Items/Model TS10(PLC)
Burn Rate 10 kg/hour
Feed Capacity 20kg
Control Mode PLC
Combustion Chamber 100L
Internal Dimensions 50x50x40cm
Secondary Chamber 50L
Smoke Filter Chamber Yes
Feed Mode Manual
Voltage 220V
Power 0.5Kw
Oil Consumption (kg/hour) 5.4–12.6
Gas Consumption (m3/hour) 6.2–11.4
Temperature Monitor Yes
Temperature Protection Yes
Oil Tank 100L
Feed Door 30x30cm
Chimney 3Meter
Chimney Type Stainless Steel
1st. Chamber Temperature 800degree–1000 degree
2nd. Chamber Temperature 1000degree-1200degree
Residency Time 2.0 Sec.
Gross Weight 1500kg
External Dimensions 140x90x120cm


Application Scope:  1. Hospital& practice: Iatric Waste, Infectious Waste, Dressing, Bio-Waste, Medicine.  2. 3. Community & Sea Port & Station: Municipal Solid Waste, etc.  4. Laboratories, Remote Locations, Disaster Relief Operations, Animal Cremation  Nanjing Clover Medical Technology Co., Ltd.  Tel: +86-25-84610201  Fax: +86-25-84610406  Nanjing City, China
