Setup on High-Temperature Pyrolysis Burning Medical That a
Basic Info.
Product Description
Nanjing Clover Medical Technology Co., Ltd.. Is a leading waste incinerator maker in China. We’re local manufacturer and one of the greatest exporter of China. Pyrolytic incinerator waste incinerator plant, waste incinerator job in vietnam 2012, waste incinerator refractor, waste incinerator sales, waste incinerator providers, waste incinerators, equipment technical is main waste treatment all of the planet, for Medical Waste, Animal Incineration, Pet cremation and other good wste. The capacity from 10kgs/Hr. To 500kgs/Hr. Up to 6ton daily. Currently we provide different show for local client requirements and design updated incinerator with our leading technology. The updated design characteristic of our assortment of incinerators make them one of the most cost effective in the world.
| Items/Model | YD-30 | YD-50 | YD-100 | YD-150 |
| Burning Rate (kgs/Hour) | 30 kgs/Hr. | 50 kgs/Hr. | 100 kgs/Hr. | 150 kgs/Hr. |
| Feed Capacity (kgs) | 60 kgs | 150 kgs | 200 kgs | 300 kgs |
| Equipment Weight | 2300 kgs | 4000 kgs | 4300 kgs | 7000 kgs |
| Primary Chamber (Liters) | 360 | 900 | 1200 | 1500 |
| Secondary Chamber (Liters) | 200 | 200 | 500 | 500 |
| External Dimensions (cm) | 145x90x175 | 200x160x230 | 220x180x360 | 240x170x380 |
| Internal Dimensions (cm) | 100x60x60 | 120x90x85 | 130x100x90 | 150x100x96 |
| Oil Tank(Liters) | 200 | 300 | 300 | 500 |
| Door Opening (cm) | 48 x 60 | 62 x 80 | 55 x 80 | 59 x 81 |
| Chimney (M) | 5 | 5 | 10 | 10 |
| Chimney Type | Stainless Steel | Stainless Steel | Stainless Steel | Stainless Steel |
| Secondary Chamber | YES | YES | YES | YES |
| Mix-Combustion Chamber | YES | YES | YES | YES |
| Smoke Filter Chamber | YES | YES | YES | YES |
| Combustion Fuel | Oil/Gas | Oil/Gas | Oil/Gas | Oil/Gas |
| Residency Time | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. | 2.0 Sec. |
| Temperature Monitoring | YES | YES | YES | YES |
