Small Incinerator (TS10 PLC)

Basic Info.

Model NO.:TS10 PLC
Pullution Sources:Solid Waste Processing
Processing Methods:Biology
Export Markets:Global

Additional Info.

Packing:Wooded Carton
Standard:10 kg per hour
Production Capacity:1500 Units/Year

Product Description

Currently , we supply different series for local client requirements and design updated incinerator with our top technology. The updated design feature of our range of incinerators create them among the most cost effective in the world.

Key Features:  * All models with Dual combustion room.  * High temperature, long life of incinerator.  * Free or minimum installation on site.  * High burn rate, from 10kgs to 600kgs a hourto 10ton daily.  * PLC Control Plane for Intelligent operation.  * One year warranty on incinerator and components in stock.

Items/Model TS10(PLC)
Burn Rate 10 kg/hour
Feed Capacity 20kg
Control Mode PLC
Combustion Chamber 100L
Internal Dimensions 50x50x40cm
Secondary Chamber 50L
Smoke Filter Chamber Yes
Feed Mode Manual
Voltage 220V
Power 0.5Kw
Oil Consumption (kg/hour) 5.4–12.6
Gas Consumption (m3/hour) 6.2–11.4
Temperature Monitor Yes
Temperature Protection Yes
Oil Tank 100L
Feed Door 30x30cm
Chimney 3Meter
Chimney Type Stainless Steel
1st. Chamber Temperature 800–1000 degree
2nd. Chamber Temperature 1000-1200 degree
Residency Time 2.0 Sec.
Gross Weight 1500kg
External Dimensions 140x90x120cm
